Body | SJ14 | Flight Parameters | SJ14 | Flight Functions and Self-protection Measures | SJ14 |
Symmetrical Motor Wheelbase | 1360mm | Empty Weight | ≤5.75KG | Low Battery Autonomous Return | Return to ground |
Arm Length | 1095mm | Takeoff Weight | ≤5.4KG(standard battery not included) | Customized Figure Calibration Flight | Import the wizard route function |
Body Diameter | 1380mm(paddles unfold) | Payload | ≤6KG | Forward view obstacle avoidance function | FPV perspective |
Landing Gear Dimensions | Height 350mm | Image Transmission Module | Standard high-definition | Out of Control Return | Return after lost link |
Motor | Flight Time 1 | 6KG payload flight time ≥70min | Return after flight attitude exceeds limit | Automatically upload terrain data in the area | |
Stator Size | 100mm | Flight Time 2 | 1.2KG payload flight time≥90min | Traditional surveying and mapping routes,strip routes,and cross routes | Customized restricted flight zone |
KV Value | 80Kv | Control Distance | ≥10KM(depending on flight environment and altitude) | Google Earth inspection tool | Collision pre-check(route and elevation check tool) |
Maximum Power | 1508w/axis | Effective Operating Altitude | 5000m | Multi-aircraft formation operations | Automatic zoning function of measurement area |
